MarkBass Little Marcus Heads

markbass little marcus head

Le MarkBass Little Marcus Heads, sono delle testate per basso che hanno la signature di Marcus Miller.

Attualmente ne esistono 4 che si distinguono in primo luogo per la potenza:

250W – 500W – 800W – 100W

MarkBass Little Marcus Heads


Little Marcus 250W

slide_little_marcus_250.jpg__1980x600_q85_subsampling-2

INPUTS

  • INPUT: impedance 500 Kohm, max. voltage 9 Vpp
  • EFFECT RETURN: impedance 33 Kohm, max. voltage 10 Vpp

CONTROLS

  • GAIN: -46 dB to +23 dB range
  • MASTER VOLUME
  • LINE OUT LEVEL
  • MUTE switch
  • GROUND LIFT (switch on rear panel)
  • PRE/POST EQ (switch on rear panel)
  • FSW input for (optional) footswitch to turn on/off EQ1 and EQ2

EQUALIZATION
EQ1

  • ULTRALOW: Level ±16 dB (Freq. 65Hz)
  • LOW: Level ±16 dB (Freq. 180Hz)
  • MID: Level ±16 dB (Freq. 500 Hz)
  • HIGH MID: Level ±16 dB (Freq. 1.4 KHz)
  • HIGH: Level ±16 dB (Freq. 3.8 KHz)

EQ2

  • OLD SCHOOL: Variable LOW PASS From 20KHz to 200Hz
  • MILLERIZER: 5-12 KHz BAND PASS Filter (Level 0 /+10 dB)

OUTPUTS

  • LINE OUT: balanced XLR, max. voltage 20 Vpp
  • EFFECT SEND: unbalanced, max. voltage 20 Vpp (pre-EQ)
  • TUNER OUT: unbalanced, max. voltage 2 Vpp
  • SPEAKER OUT: speakon combo

OTHER

  • WEIGHT: 5.29 lbs / 2.4 Kg
  • WIDTH: 10.87 in. / 27.6 cm
  • DEPTH: 9.84 in. / 25 cm
  • HEIGHT: 3.27 in. / 8.3 cm
  • OUTPUT POWER: 250W RMS @ 4 ohms / 150W RMS @ 8 ohms
  • POWER REQUIREMENT: 100/120V; 230V; 240V – 50/60Hz (Voltage is factory preset according to region of sale)

Little Marcus 500W

markbass little marcus head

INPUTS

  • INPUT: impedance 500 Kohm, max. voltage 9 Vpp
  • EFFECT RETURN: impedance 33 Kohm, max. voltage 10 Vpp

CONTROLS

  • GAIN: -46 dB to +23 dB range
  • MASTER VOLUME
  • LINE OUT LEVEL
  • MUTE switch
  • GROUND LIFT (switch on rear panel)
  • PRE/POST EQ (switch on rear panel)
  • FSW input for (optional) footswitch to turn on/off EQ1 and EQ2

EQUALIZATION
EQ1

  • ULTRALOW: Level ±16 dB (Freq. 65Hz)
  • LOW: Level ±16 dB (Freq. 180Hz)
  • MID: Level ±16 dB (Freq. 500 Hz)
  • HIGH MID: Level ±16 dB (Freq. 1.4 KHz)
  • HIGH: Level ±16 dB (Freq. 3.8 KHz)

EQ2

  • OLD SCHOOL: Variable LOW PASS From 20KHz to 200Hz
  • MILLERIZER: 5-12 KHz BAND PASS Filter (Level 0 /+10 dB)

OUTPUTS

  • LINE OUT: balanced XLR, max. voltage 20 Vpp
  • EFFECT SEND: unbalanced, max. voltage 20 Vpp (pre-EQ)
  • TUNER OUT: unbalanced, max. voltage 2 Vpp
  • SPEAKER OUT: speakon combo

OTHER

  • WEIGHT: 5.29 lbs / 2.4 Kg
  • WIDTH: 10.87 in. / 27.6 cm
  • DEPTH: 9.84 in. / 25 cm
  • HEIGHT: 3.27 in. / 8.3 cm
  • OUTPUT POWER: 500W RMS @ 4 ohms / 300W RMS @ 8 ohms
  • POWER REQUIREMENT: 100/120V; 230V; 240V – 50/60Hz (Voltage is factory preset according to region of sale)

Little Marcus 800W

markbass little marcus head 800

INPUTS

  • INPUT: impedance 500 Kohm, max. voltage 9 Vpp
  • EFFECT RETURN: impedance 33 Kohm, max. voltage 10 Vpp

CONTROLS

  • GAIN: -46 dB to +23 dB range
  • MASTER VOLUME
  • LINE OUT LEVEL
  • MUTE switch
  • GROUND LIFT (switch on rear panel)
  • PRE/POST EQ (switch on rear panel)
  • FSW input for (optional) footswitch to turn on/off EQ1 and EQ2

EQUALIZATION
EQ1

  • ULTRALOW: Level ±16 dB (Freq. 65Hz)
  • LOW: Level ±16 dB (Freq. 180Hz)
  • MID: Level ±16 dB (Freq. 500 Hz)
  • HIGH MID: Level ±16 dB (Freq. 1.4 KHz)
  • HIGH: Level ±16 dB (Freq. 3.8 KHz)

EQ2

  • OLD SCHOOL: Variable LOW PASS From 20KHz to 200Hz
  • MILLERIZER: 5-12 KHz BAND PASS Filter (Level 0 /+10 dB)

OUTPUTS

  • LINE OUT: balanced XLR, max. voltage 20 Vpp
  • EFFECT SEND: unbalanced, max. voltage 20 Vpp (pre-EQ)
  • TUNER OUT: unbalanced, max. voltage 2 Vpp
  • SPEAKER OUT: speakon combo

OTHER

  • WEIGHT: 6.61 lbs / 3 Kg
  • WIDTH: 10.87 in. / 27.6 cm
  • DEPTH: 9.84 in. / 25 cm
  • HEIGHT: 3.27 in. / 8.3 cm
  • OUTPUT POWER: 800W RMS @ 4 ohms / 500W RMS @ 8 ohms
  • POWER REQUIREMENT:100/120V; 230V; 240V – 50/60Hz (Voltage is factory preset according to region of sale)

Little Marcus 1000W

markbass little marcus head 1000

INPUTS

  • INPUT: impedance 500 Kohm, max. voltage 9 Vpp
  • EFFECT RETURN: impedance 33 Kohm, max. voltage 10 Vpp

CONTROLS

  • GAIN: -46 dB to +23 dB range
  • MASTER VOLUME
  • LINE OUT LEVEL
  • MUTE switch
  • GROUND LIFT (switch on rear panel)
  • PRE/POST EQ (switch on rear panel)
  • FSW input for (optional) footswitch to turn on/off EQ1 and EQ2

EQUALIZATION
EQ1

  • ULTRALOW: Level ±16 dB (Freq. 65Hz)
  • LOW: Level ±16 dB (Freq. 180Hz)
  • MID: Level ±16 dB (Freq. 500 Hz)
  • HIGH MID: Level ±16 dB (Freq. 1.4 KHz)
  • HIGH: Level ±16 dB (Freq. 3.8 KHz)

EQ2

  • OLD SCHOOL: Variable LOW PASS From 20KHz to 200Hz
  • MILLERIZER: 5-12 KHz BAND PASS Filter (Level 0 /+10 dB)

OUTPUTS

  • LINE OUT: balanced XLR, max. voltage 20 Vpp
  • EFFECT SEND: unbalanced, max. voltage 20 Vpp (pre-EQ)
  • TUNER OUT: unbalanced, max. voltage 2 Vpp
  • SPEAKER OUT: speakon

OTHER

  • WEIGHT: 6.39 lbs / 2.9 Kg
  • WIDTH: 10.87 in. / 27.6 cm
  • DEPTH: 9.84 in. / 25 cm
  • HEIGHT: 3.27 in. / 8.3 cm
  • OUTPUT POWER: 1000W RMS @ 4 ohms / 600W RMS @ 8 ohms
  • POWER REQUIREMENT: 100/120V; 230V; 240V – 50/60Hz (Voltage is factory preset according to region of sale)
