Descrizione
Features
● B1 FOUR offers over 60 built-in effects
● B1X FOUR offers over 70 built-in effects
● 9 amp models for simulating classic rigs
● Up to 5 effects can be used simultaneously, chained together in any order
● Built-in expression pedal for control over any parameter (B1X FOUR only)
● Looper for recording up to 30 seconds / 64 beats of CD-quality audio
● ZOOM Guitar Lab software for creating, editing and managing effects and patches
● 68 built-in rhythm patterns which can be used in conjunction with the Looper
● 50 memory locations for storing user-created patches
● Auto Save function for automatic saving of all patch parameters
● PRESELECT function allows silent patch selection while the current patch remains operational
● Onboard chromatic tuner
● Input jack accepts standard mono bass guitar cable (both active and passive instruments supported)
● Auxiliary input jack for connection of personal music players
● Output jack for connection to amp or headphones
● Lightweight and small enough to fit in your gig bag
● Easily integrated into any existing pedal board
● Runs on 4 AA batteries, with alkaline battery life of 18 hours
● USB port for firmware updates, power and connection to ZOOM Guitar Lab
SPECS
| Maximum number of simultaneous effects: | 5 |
|---|---|
| User patches: | 50 |
| Sampling frequency : | 44.1 kHz |
| A/D conversion: | 24-bit, 128× oversampling |
| D/A conversion : | 24-bit, 128× oversampling |
| Signal processing : | 32−bit |
| Display: | 128×32 dot matrix LCD |
| INPUT | |
| INPUT : | Standard mono phone jack Rated input level: -20 dBu Input impedance (line): 470 kΩ |
| AUX IN : | Stereo mini jack Rated input level: -10 dBu Input impedance (line): 1kΩ |
| OUTPUT | |
| OUTPUT: | Standard stereo phone jack (combined line/headphone) Maximum output level: Line +2 dBu (10 kΩ or more output impedance) Headphones 17 mW + 17 mW (32Ω load) |
| Input S/N : | 120 dB |
| Noise floor (residual noise) : | -97 dBu |
| Power : | Power AC adapter: 9V DC 500mA center negative (ZOOM AD-16) 4 AA batteries (about 18 hours continuous operation time when using alkaline batteries with the LCD backlight off) |
| USB : | Connector: USB2.0 Micro-B
Guitar Lab Supported cable: USB2.0 Micro-B cable |
| External dimensions : | B1 FOUR 156 mm (D) × 130 mm (W) × 42 mm (H) B1X FOUR 156 mm (D) × 216 mm (W) × 52 mm (H)
|
| Weight: | B1 FOUR 340 g (excluding batteries) B1X FOUR 610 g (excluding batteries)
|
| * Note: 0 dBu = 0.775 V | |
